Cuppone Alpha Pizza Oven

Cuppone Alpha Pizza Oven

Forno Alpha: precisione e flessibilità in un unico forno.
Alpha’s rotary cooking plate can be adjusted in speed and direction, thus guaranteeing uniform and perfect baking results. Highly customized baking processes are allowed by differentiated temperatures of top element and bed plate. A professional oven designed to meet the needs of the most demanding pizza chefs.
The Alpha professional oven was designed to meet the needs of very demanding pizza chefs. New-generation LED lights offer unprecedented lighting, while the new glass panel allows enhanced visual control over the baking process through the door. Being made of steel and featuring a secondary coated face, Alpha ensures excellent thermal insulation. Innovative lines and a sharper design make this oven a unique product.
The new hood is larger and offers enhanced performance, allowing to capture more fumes and vapors. Ideal for intensive-use environments, this hood keeps the air clean and improves comfort and quality in the cooking area.
It was specifically designed to allow to pass through 80cm-wide doors, thanks to its special support, so that you can easily place the oven in any corner of your kitchen. Robust structure and high-quality materials ensure excellent performance over time.
Available in two versions: AO100 model, with cooking chamber Ø 1100 mm, and AO140 model, with cooking chamber Ø 1400 mm.

Special features

• Touch screen control system
• Differentiated ceiling and floor temperature
• Control of the direction and the speed of the cooking plate rotation
• Heat seal between door and cooking chamber
• Top/Floor differentiated heating elements
• high-visibility glass panel
• Cooking programming
• Timer

Optional Equipment

• Napoli kit (25 mm stones) - Cloud connection - Boosted heating elements - Peel holder

Technical specifications AO110 model

External dimensions(LxPxH): 1388x1438x1697 mm
Weight: 527 kg
Cooking chamber dimensions: Ø 1100 mm - h 180 mm
Door dimensions: 620 x h120 mm
Maximum temperature: 450°C
Total cooking capacity: 8 pizzas Ø 300 mm / 2 teglie 400x600 mm
Productivity per hour (classic pizza): 80 pizzas Ø 300 mm / 12 trays 400x600 mm
Electric power supply: 400V/3N/50-60Hz
Maximum absorption: 16.2 kW
Average consumption: 9.7 kWh

Technical specifications AO140 model

External dimensions(LxPxH): 1688x1738x1697 mm
Weight: 646 kg
Cooking chamber dimensions: Ø 1400 mm - h 180 mm
Door dimensions: 620 x h120 mm
Maximum temperature: 450°C
Total cooking capacity: 14 pizzas Ø 300 mm / 4 teglie 400x600 mm
Productivity per hour (classic pizza): 140 pizzas Ø 300 mm / 24 trays 400x600 mm
Electric power supply: 400V/3N/50-60Hz
Maximum absorption: 19.9 kW
Average consumption: 11.9 kWh
